About LUNAR SHINE - LED TUBES

High quality integrated led tube fixture with excellent lumens & power saving feature. non corrosive and uv resistant pvc housing & duffers provides excellent performance. available in 1, 2 & 4 feet sizes. easy installation & highly durable.

Applications

  • Industrial
  • House
  • Hospital
  • School
  • Office
  • & more.

Colors

  • LED Tubes colors
  • LED Tubes colors
  • LED Tubes colors

Products

  • 24W LUNAR SHINE

Product Code

  • SP-T5 LED LU-24W

Buy Now at:

Features & Benefits

Good solution for replacing 2 x 36w battens uninterrupted linear appearance with sleek profile of 70mm height & 50mm width available in options of 4' and 8' feet.

Product Details

Range/Wattage Product Code Lumens Length (mm) Case Size
5W SP-T5 LED LU-5W 500 lm 300 mm 20
10W SP-T5 LED LU-10W 1000 lm 600 mm 20
20W SP-T5 LED LU-20W 2000 lm 1192 mm 25
22W SP-T5 LED LU-22W 2200 lm 1192 mm 25
24W SP-T5 LED LU-24W 2400 lm 1192 mm 25

Technical Specifications

Wattage CCT Shape Body Material Warranty Technical Data
5W 6500K/4000K/2700K Square PC 24 month 100-300 VAC, PF >0.9, THD <20%, CRI -80, 50Hz
10W 6500K/4000K/2700K Square PC 24 month 100-300 VAC, PF >0.9, THD <20%, CRI -80, 50Hz
20W 6500K/4000K/2700K Square PC 24 month 100-300 VAC, PF >0.9, THD <20%, CRI -80, 50Hz
22W 6500K/4000K/2700K Square PC 24 month 100-300 VAC, PF >0.9, THD <20%, CRI -80, 50Hz
24W 6500K/4000K/2700K Square PC 24 month 100-300 VAC, PF >0.9, THD <20%, CRI -80, 50Hz
